metal plate small laser cutter , small laser metal cutting machine 60m / min

detalji o proizvodu

Certifikacija: ISO9001: 2008

Uvjeti plaćanja i slanja:

Minimalna količina narudžbe: 1 jedinica

Cijena: pregovaranje

Detalji pakiranja: Drvena futrola

Vrijeme isporuke: 7-15 dana

Sposobnost snabdijevanja: 2000 jedinica mjesečno

Detaljan opis proizvoda

Ime proizvoda:	Laserski stroj za rezanje vlakana	Laserska snaga:	500W / 800W
Radno područje:	500 * 500mm	Maksimalna brzina kretanja:	60m / min
Točnost pozicioniranja:	± 0.01-0.03	Snaga opskrbe:	3 × 380 V ± 10% 220 V ± 10%
Paket:	Drvena kutija	jamstvo:	1 godina

Opis proizvoda

precision laser cutting machine is designed and made by RISE LASER. Adopted with leading laser technology for thin sheet metal application. The machine is combined with marble and Cypcut laser cutting system. With Integrated designing, dual gantry linear motor driving system, friendly interface and long term stable working.

Glavne značajke

1. Easy to operate: Adopted world’s leading technology EtherCAT bus USA cnc laser cutting system, very easy to operate;
2. Safe and compact structure: small size, very suitable for small and medium factories processing production;
3. High efficient and high speed: adopted double drive liner motor drive system, effectively improve the cutting accuracy and production efficiency;
4. Fiber laser source: adopted Maxphotonics laser source, which is the first domestic brand of the stable and reliable medium power laser source;
5. Precision cutting: adopted Swiss RAYTOOLS professional laser cutting head, to ensure the best cutting results;
6. Stable and durable: the machine tool is adopted granite marble, can keep shape and is high stable, which can effectively eliminate the shock generated by the high speed cutting processing;
7. Anti-corrosion, wear-resistant: the transmission parts is free maintenance, can cut corrosive materials.

Konfiguracija

^#	^Artikal	^{Specifikacija}	^marka	^Napomena
¹	^{Laserski izvor}	^800W	^Maxphotonics
²	^{linearni motor}
³	^{Optička rešetka}	^{razlučivost 0,5µm}	^Španija
⁴	^Vozač		^servotronix
⁵	^{Z osi grupa modula vijaka}
⁶	^{Glava za rezanje laserom}	^BT230
⁷	^{Precizna linearna vodilica}		^Hiwin
⁸	^Mramor	^{18001350200}	^Shandong
⁹	^{Organski pokrov}	^Standard
¹⁰	^{Strojni materijal}	^Standard		^{zrakoplovna aluminijska legura}

Parametar

^{Radna veličina}		^{500 × 500 (mm)}
^{Maks. Ubrzanje}		^1.2g
^{X AXIS}	^{Maks. Brzina kretanja}	^{60m / min}
	^put	^500mm
	^{Točnost pozicioniranja}	^{± 0.01mm}
	^{Točnost ponavljanja}	^{± 0.004mm}
^{Y OSI}	^{Maks. Brzina kretanja}	^{60m / min}
	^put	^500mm
	^{Točnost pozicioniranja}	^{± 0.01mm}
	^{Točnost ponavljanja}	^{± 0.004mm}
^{Z AXIS}	^put	^100mm

Radni uvjeti

¹	^{Radna temperatura}	^{-10 ℃ ~ 45 ℃}
²	^{Relativna vlaga}	^{＜ 90% bez kondenzatora}
³	^okolina	^{Dobra ventilacija, bez vibracija}
⁴	^Napajanje	^{3 × 380 V ± 10% 220 V ± 10%}
⁵	^{Frekvencija napajanja}	^50Hz

Primjena preciznog stroja za lasersko rezanje vlakana

Pogodno za ugljični čelik, blagi čelik, SS ploču, aluminijsku leguru i bakrenu ploču i druge metale. Pogodan je za obradu materijala srednje i tanke debljine.
Primjenjuju se u obradi lima, zrakoplovstvu, zrakoplovstvu, elektronici, električnim aparatima, cijevima, automobilskim, prehrambenim strojevima, tekstilnim strojevima, inženjerskim strojevima, preciznim dijelovima, brodovima, metalurškoj opremi, dizačima, kućanskim aparatima, obradi lima, kuhinjskim priborom i uređajima , obrtnički pokloni, obrada alata, dekoracija, oglašavanje, obrada metala i druga prerađivačka industrija.
